Bale Wrappers
Specifications
| BW5500 | SBW8500 | |
|---|---|---|
| Availability | OUT OF STOCK | OUT OF STOCK |
| Price | 13 HP No Drive - $47,470 | $35,740 |
| 13 HP Dual Drive - $49,890 | ||
| 20 HP No Drive - $50,380 | ||
| 20 HP Dual Drive - $52,800 | ||
| Dimensions & Weights | ||
| Transport Length | 18 ft (5.5 m) | 19 ft (5.8 m) |
| Transport Height | 9 ft (2.7 m) | 9 ft (2.7 m) |
| Transport Width | 8 ft (2.4 m) | 7.4 ft (2.3 m) |
| Machine Weight | 5,000 lb | 4,600 lb |
| Tires | (2) 11L x 15-8 | 380/55x17 |
| (2) 27 x 10.5 traction | ||
| Specifications | ||
| Engine | 13 gp or 20 hp | N/A |
| Engine Start | Electric | N/A |
| PTO Horsepower Recommended | N/A | 55 hp |
| Hydraulics | Self-contained | 1 single acting, return to tank |
| Hydraulic Flow Rate | N/A | 6-8 gpm |
| Control System | Digital with LCD display | Digital Controller with 4.3" color touchscreen & keypad |
| Hitch | Drawbar | Drawbar |
| Steering | Electric over hydraulic jack | N/A |
| Film Strecher | (3) 30" x 55% | 55% or 70% |
| Bale Alginmet | Fixed bale guides | N/A |
| Wrapping Capacity | 120 bales/hour | N/A |
| Hoop Speed | Digital controller adjusted | N/A |
| Bale Size Maximum | 6 ft x 5 ft round | 5.2 ft x 5 ft |
| BW5500 | SBW8500 | |
|---|---|---|
| Features | ||
| Remote Steer, Engine Start Stop | Optional | N/A |
| LED Work Lights | Optional | N/A |
| Discharge Guide Rollers | Optional | N/A |
| Plastic Sensor Alert | Optional | N/A |
| Spring-Assisted Final Bale Push Off | Optional | N/A |
| Laser Guidance | Optional | N/A |
