Overview

 * Kawasaki FX Engine - Full Commercial Remote Canister Air Cleaner
 * Premium Seat - High-back seat with suspension to shield the operator from bumps & EVC cushion to take pressure off tailbone & lower back
 * BigBite Rear Tires - For smooth ride & enhanced traction
 * Foot Operated Deck Lift - Easily adjust the deck height between 1.5" - 4.5" with your foot
 * Easy Serviceability - Flip-up seat pan, removeable floor pan, & tooless removable pulley covers makes maintenance easy & simple
 * Fabricated Frame for Durability - 1.5" x 3.0" steel frame making it one of the toughest & most durable in its class
 * Welded Steel Deck - Durable 10 ga. welded fabricated steel
 * SmoothTrak Steering - Precision control to help trim & maneuver easily around obstacles. You will fully understand SmoothTrak steering when you drive ours and then drive theirs
 * Serviceable Commercial Grade Transmission - Hydro-Gear ZT-3400
 * Limited 4 Year/1000 Hour Warranty

Specifications
Deck Size 48" 54" 60"
Availability OUT OF STOCK In Stock OUT OF STOCK
Price $10,729 $10,958 $11,300
Engine Manufacturer Kawasaki Kawasaki Kawasaki
Engine HP 22 HP - FX691 22 HP - FX691 23.5 HP - FX730
Engine Displacement 726 cc 726 cc 726 cc
Eninge Cooling Air Cooled Air Cooled Air Cooled
Engine Warranty 3 Year 3 Year 3 Year
Drive System Type Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic
Transmission Hydro-Gear ZT3400 Hydro-Gear ZT3400 Hydro-Gear ZT3400
Speed Up to 9 MPH Up to 9 MPH Up to 9 MPH
Parking Brake Patented automatic Patented automatic Patented automatic
Cutting Height 1.5" - 4.5" 1.5" - 4.5" 1.5" - 4.5"
Deck Lift Foot Operated Foot Operated Foot Operated
Deck Depth 5.0" 5.0" 5.0"
Blades 3 3 3
Blade Length 16.50" 18.50" 20.50"
Blade Tip Speed 18,600 18,900 18,400
Deck Spindles Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings
Deck Drive Electric PTO Clutch Electric PTO Clutch Electric PTO Clutch
Deck Construction Fabricated 10 ga. steel Fabricated 10 ga. steel Fabricated 10 ga. steel
Deck Spindle Mounts Reinforced 11 ga. steel Reinforced 11 ga. steel Reinforced 11 ga. steel
Impact/Trim Areas 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge
Frame 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing
Front Axle Fabricated with sealed ball bearings Fabricated with sealed ball bearings Fabricated with sealed ball bearings
Front Caster Wheels Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable
Front Caster Forks Fabricated 3/8" steel Fabricated 3/8" steel Fabricated 3/8" steel
Seat Extra High-back suspension seat Extra High-back suspension seat Extra High-back suspension seat
Fuel Capacity 5 gallons 5 gallons 5 gallons
Cupholder Yes Yes Yes
(continued) Deck Size 48" 54" 60"
Front Tire 13 x 5-6 13 x 6.5 - 6 13 x 6.5 - 6
Drive Tire 23 x 9.5 - 10 Big Bite 23 x 11 -10 Big Bite 23 x 11 -10 Big Bite
Weight 862 lbs 891 lbs 916 lbs
Height 48.9" / 68.7 w/ ROPS up 48.9" / 68.7 w/ ROPS up 48.9" / 68.7 w/ ROPS up
Length 73.6" 74.42" 75.92"
Width w/Chute Up 49.1" 55.1" 61.1"
Tire Width 47" 52" 52"
Trim Side 1" 3" 6"
Acres per Hour (80% efficiency) 3.49 3.93 4.36
Warranty 4 Year / 1000 Hour 4 Year / 1000 Hour 4 Year / 1000 Hour
