Overview

 * SmoothTrak Steering - Precision control to help trim & maneuver easily around obstables. Other brands have sensitive steering arms causing sudded & jerky movements
 * Hydraulic Deck Height Adjustment - Raising & lowering your cutting height has never been easier
 * HyperDrive Hydro System - Features industrial-grade pumps & motors to handle tough jobs & long days
 * I3M Suspension Seat - High-back seat with adjustable armrests & 3" travel range
 * Commercial-Grade Engines - Vanguard Big Block EFI with Oil Guard, Kawasaki F1000 & Kawasaki FX1000 EFI engine options
 * Hydraulic Wings - Easily raise & lower wings for transporting
 * 80" Transport Width - Fits most trailer making it easy to ransport from job-to-job
 * 104" Width of Cut - Widest & most productive commercial zero-turn available
 * Mows a football field in under 10 minutes

Specifications
Deck Size 104" 104" 104"
Availability OUT OF STOCK OUT OF STOCK OUT OF STOCK
Price $33,790 $34,703 $35,616
Engine Manufacturer Kawasaki Kawasaki Vanguard
Engine HP 35 HP - FX1000 38.5 HP - FX1000 EFI 40 HP - Big Block EFI w/ Oil Guard
Displacement 999 cc 999 cc 993 cc
Cooling Air cooled Air cooled Air cooled
Air Cleaner Heavy Duty Canister Heavy Duty Canister Heavy Duty Canister
Engine Warranty 3 Year 3 Year 3 Year
Drive System Type Dual hydrostatic Dual hydrostatic Dual hydrostatic
Pumps Danfoss DDC20 Danfoss DDC20 Danfoss DDC20
Wheel Motors Parker TG Parker TG Parker TG
Hydraulic Lines Stainless steel Parker Seal-Lok technology Stainless steel Parker Seal-Lok technology Stainless steel Parker Seal-Lok technology
Reservoir Capcity 3 gallons 3 gallons 3 gallons
Speed Up to 11 MPH Up to 11 MPH Up to 11 MPH
Parking Brakes Integrated with steering levers Integrated with steering levers Integrated with steering levers
Cutting Height 1" - 5.5" 1" - 5.5" 1" - 5.5"
Deck Lift Hydraulic Powered Hydraulic Powered Hydraulic Powered
Deck Depth 5.5" 5.5" 5.5"
Blaes 5 5 5
Blade Length 1 - 23.86 CW, 1 - 23.86 CCW, 1 - 20.5 CCW, 2 - 20.5 CW 1 - 23.86 CW, 1 - 23.86 CCW, 1 - 20.5 CCW, 2 - 20.5 CW 1 - 23.86 CW, 1 - 23.86 CCW, 1 - 20.5 CCW, 2 - 20.5 CW
Blade Tip Speed Wing Decks - 15,800, Center Deck - 15,500 Wing Decks - 15,800, Center Deck - 15,500 Wing Decks - 15,800, Center Deck - 15,500
Spindles Ductile cast iron with steel shafts & sealed ball bearings Ductile cast iron with steel shafts & sealed ball bearings Ductile cast iron with steel shafts & sealed ball bearings
Drive Electric PTO clutch Electric PTO clutch Electric PTO clutch
Construction 11 g. welded steel 11 g. welded steel 11 g. welded steel
Spindle Mounts Reinforced 7 ga. doubler Reinforced 7 ga. doubler Reinforced 7 ga. doubler
Impact/Trim Areas 1.5" x .375" steel bar 1.5" x .375" steel bar 1.5" x .375" steel bar
Frame Construction 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing
Front Axle Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings
Front Caseter Wheels Tapered wheel bearings & debris cap Tapered wheel bearings & debris cap Tapered wheel bearings & debris cap
(continued) Deck Size 104" 104" 104"
Seat I3M suspension seat, adjustable armrests & back I3M suspension seat, adjustable armrests & back I3M suspension seat, adjustable armrests & back
Fuel Capacity 12 gallons 12 gallons 12 gallons
Cupholder Yes Yes Yes
Front Tire 15 x 6.0 - 6 15 x 6.0 - 6 15 x 6.0 - 6
Drive Tire 26 x 12 - 12 26 x 12 - 12 26 x 12 - 12
Wing Tire 11 x 4 semi pneumatic 11 x 4 semi pneumatic 11 x 4 semi pneumatic
Weight 2,500 lbs 2,500 lbs 2,500 lbs
Height 54", 71.5" w/ ROPS up 54", 71.5" w/ ROPS up 54", 71.5" w/ ROPS up
Length 95.5" 95.5" 95.5"
Width 106.1" wings down, 80" wings up at gauge wheels, 72.5" wings up at deck base 106.1" wings down, 80" wings up at gauge wheels, 72.5" wings up at deck base 106.1" wings down, 80" wings up at gauge wheels, 72.5" wings up at deck base
Tire Width 60.3" 60.3" 60.3"
Trim Side 23.2" 23.2" 23.2"
Acres per Hour 9.24 9.24 9.24
Warranty 5 Year 1200 Hour 5 Year 1200 Hour 5 Year 1200 Hour
