TrimStar
Overview
* H-bar Steering = Patened steering is the easiest-to-use walk-behing in the field, reducing operator fatigue
* Ergo-designed controls - Reduces operator fatigue
* Compact Stance - Better maneuvering in tight spaces
Specifications
| Deck Size | 36" | 48" | 54" | 60" |
|---|---|---|---|---|
| Availability | OUT OF STOCK | In Stock | OUT OF STOCK | OUT OF STOCK |
| Price | $7,990 | $8,218 | $9,017 | $9,474 |
| Engine Manufacturer | Kawasaki | Kawasaki | Kawasaki | Kawasaki |
| Engine HP | 15 HP - FS600 | 18.5 HP - FS600 | 22 HP - FS651 | 23 HP - FS691 |
| Displacement | 603 cc | 603 cc | 726 cc | 726 cc |
| Cooling | Air cooled | Air cooled | Air cooled | Air cooled |
| Air Cleaner | Oval Canister, dual element | Oval Canister, dual element | Oval Canister, dual element | Oval Canister, dual element |
| Engine Warranty | 3 year | 3 year | 3 year | 3 year |
| Drive System Type | Dual hydrostatic | Dual hydrostatic | Dual hydrostatic | Dual hydrostatic |
| Transmission | Hydro-Gear ZT-2800 | Hydro-Gear ZT-2800 | Hydro-Gear ZT-2800 | Hydro-Gear ZT-2800 |
| Hydraulic Cooling | Pump mounted fans | Pump mounted fans | Pump mounted fans | Pump mounted fans |
| Speed | Up to 6.3 MPH | Up to 6.3 MPH | Up to 6.3 MPH | Up to 6.3 MPH |
| Parking Brakes | Internal transmission mechanical brake | Internal transmission mechanical brake | Internal transmission mechanical brake | Internal transmission mechanical brake |
| Cutting Height | 1.5" - 4.5" | 1.5" - 4.5" | 1.5" - 4.5" | 1.5" - 4.5" |
| Deck Lift | Hand operated | Hand operated | Hand operated | Hand operated |
| Deck Depth | 5" | 5" | 5" | 5" |
| Blades | 2 | 3 | 3 | 3 |
| Blade Length | 17.86" | 16.5" | 18.5" | 20.5" |
| Blade Tip Speed | 18,400 | 18,500 | 18,800 | 18,400 |
| Spindles | Aluminum w/ steel shaft & sealed ball bearings | Aluminum w/ steel shaft & sealed ball bearings | Aluminum w/ steel shaft & sealed ball bearings | Aluminum w/ steel shaft & sealed ball bearings |
| Drive | Electric PTO | Electric PTO | Electric PTO | Electric PTO |
| Construction | 7 ga. + 7 ga. reinforced steel | 10 ga. + 11 ga. reinforced steel | 10 ga. + 11 ga. reinforced steel | 10 ga. + 11 ga. reinforced steel |
| Impact/Trim Areas | 11 ga. formed channel rolled edge | 11 ga. formed channel rolled edge | 11 ga. formed channel rolled edge | 11 ga. formed channel rolled edge |
| Frame Construction | 1.5" x 2" steel tubing | 1.5" x 2" steel tubing | 1.5" x 2" steel tubing | 1.5" x 2" steel tubing |
| Front Axle Construction | Fabricated with tapered roller bearings | Fabricated with tapered roller bearings | Fabricated with tapered roller bearings | Fabricated with tapered roller bearings |
| Front Caster Wheels | Tapered wheel bearings & debris cap | Tapered wheel bearings & debris cap | Tapered wheel bearings & debris cap | Tapered wheel bearings & debris cap |
| Front Caster Forks | Fabricated 3/8" steel | Fabricated 3/8" steel | Fabricated 3/8" steel | Fabricated 3/8" steel |
| Fuel Capacity | 3.4 gallons | 3.4 gallons | 3.4 gallons | 3.4 gallons |
| Cupholder | No | No | No | No |
| (continued) Deck Size | 36" | 48" | 54" | 60" |
|---|---|---|---|---|
| Front Tire | 11 x 4 - 5 semi pneumatic | 11 x 4 - 5 semi pneumatic | 11 x 4 - 5 semi pneumatic | 11 x 4 - 5 semi pneumatic |
| Drive Tire | 20 x 6.5 - 10 | 20 x 8 - 10 | 20 x 10 - 10 | 20 x 10 - 10 |
| Weight | 560 lbs | 635 lbs | 660 lbs | 695 lbs |
| Height | 42.5" | 42.5" | 42.5" | 42.5" |
| Length | 76.7" | 75" | 75.3" | 77.5" |
| Width w/ Chute Up | 37" | 49" | 55" | 61" |
| Tire Width | 35" | 44" | 46" | 46" |
| Trim Side | .9" | 2.4" | 5.5" | 8.4" |
| Acres Per Hour | 1.88 | 2.44 | 2.75 | 3.06 |
| Warranty | 5 Year 1200 Hour | 5 Year 1200 Hour | 5 Year 1200 Hour | 5 Year 1200 Hour |
