Overview

 * Commercial-Grade Engines - Kawasaki FX Engine backed by 3 year warranty
 * I3M Seat - High-back seat with adjustable armrests & 3" suspension travel range
 * Foot Operated Deck Lift - Easily adjust the deck height between 1.5" - 5.5" with your foot
 * Fabricated Frame for Durability - 1.5" x 3.0" steel frame making it one of the toughest & most durable in its class
 * VX Deck - Fabricated 7 ga. steel engineered for extreme vacuum for enhanced performance & cut quality
 * SmoothTrak Steering - Precision control to help trim & maneuver easily around obstacles. You will fully understand SmoothTrak steering when you drive ours and then drive theirs
 * Commercial-grade Torque - Driven by parker unitized transmissions
 * Limited 2 Year/No Hour Limit or 5 Year/500 Hour Warranty

Specifications
Deck Size 52" 52" 54" RD 60" 60" 60" 60" 60" 60" 60" RD 72" 72" 72"
Availability OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK OUT OF STOCK
Price $12,442 $13,241 $13,355 $12,556 $12,556 $12,898 $13,127 $13,697 $14,611 $13,583 12,784 $13,926 $14,839
Engine Manufacturer Kohler Kawasaki Kawasaki Kohler VanGuard Kawasaki Kawasaki Kawasaki Kawasaki Kawasaki VanGuard Kawasaki Kawasaki
Engine HP 25 HP - Command Pro 27 HP - FX850 23.5 HP - FX730 25 HP - Command Pro 26 HP 24 HP - FT730 23.5 HP - FX730 27 HP - FX850 29.5 HP - FX850 EFI 23.5 HP - FX730 26 HP 27 HP - FX850 29.5 HP - FX850 EFI
Engine Displacement 725 cc 852 cc 726 cc 725 cc 810 cc 726 cc 726 cc 852 cc 852 cc 726 cc 810 cc 852 cc 852 cc
Engine Cooling Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled
Engine Air Cleaner Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister Heavy duty canister
Engine Warranty 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year 3 Year
Drive System Type Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic Dual hydrostatic
Transmission Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors Parker unitized 12cc/rev pump & 15.9ci/rev wheel motors
Speed up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH up to 10.5 MPH
Parking Brake Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic
Cutting Height 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5" 1" - 5.5"
Deck Lift Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated
Deck Depth 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5"
Deck Blades 3 3 3 3 3 3 3 3 3 3 3 3 3
Deck Blade Length 17.86" 17.86" 18.5" 20.50" 20.50" 20.50" 20.50" 20.50" 20.50" 20.50" 23.86" 23.86" 23.86"
Blade Tip Speed 17,700 17,700 18,300 18,800 18,800 18,800 18,800 18,800 18,800 18,800 18,500 18,500 18,500
Deck Spindles Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings Ductilecast iron with steel shafts and sealed ball bearings
Deck Drive Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch
Deck Constrution Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers Fabricated 7 ga. with 7 ga. wrappers
Deck Spindle Mounts Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc 10 ga. with 11 ga. doubler Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc 10 ga. with 11 ga. doubler Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc Reinforced 7 ga. stamped disc
Impact/Trim Areas 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge 11 ga. formed channel with rolled edge
Frame Construction 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing 1.5" x 3.0 steel tubing
Front Axle Construction Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings Fabricated with tapered roller bearings
Front Caster Wheels Construction Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap Mounted with tapered greasable bearings & debris cap
Front Caster Forks Construction Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel Fabricated 1/2" steel
Seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat I3M suspension seat
Fuel Capacity 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons 11.7 gallons
(continued) Deck Size 52" 52" 54" RD 60" 60" 60" 60" 60" 60" 60" RD 72" 72" 72"
Cup Holder Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Front Tire 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6
Drive Tire 24 x 9.5 -12 24 x 9.5 -12 24 x 9.5 -12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12 24 x 12 - 12
Weight 1,240 lbs 1,240 lbs 1,275 lbs 1,290 lbs 1,245 lbs 1,245 lbs 1,245 lbs 1,245 lbs 1,305 lbs 1,320 lbs 1,320 lbs 1,320 lbs
Height w/ ROPS up 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5" 72.5"
Height w/ ROPS folded 49" 49" 49" 49" 49" 49" 49" 49" 49" 49" 49" 49" 49"
Length 80.2" 80.2" 80.2" 80.2" 80.2" 80.2" 80.2" 80.2" 80.2" 80.2" 84" 84" 84"
Width 54.4" 54.4" 55.72" 62.4" 62.4" 62.4" 62.4" 62.4" 62.4" 61.72" 75.7" 75.7" 75.7"
Tire Width 51" 51" 51" 54.5" 54.5" 54.5" 54.5" 54.5" 54.5" 54.5" 54.5" 54.5" 54.5"
Trim Side 1.4" 1.4" 2.7" 3.2" 3.2" 3.2" 3.2" 3.2" 3.2" 3.2" 11.7" 11.7" 11.7"
Acres Per Hour 5.52 5.52 5.73 6.36 6.36 6.36 6.36 6.36 6.36 6.36 7.64 7.64 7.64
Warranty 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour 2 Year No Hour Limit / 5 Year 500 Hour
